PINNACLE MARQUEE OUTDOOR EVENT TENT

The Pinnacle Range of event tents is a stylish collection of pagoda marquees. These tents will add extra class to any outdoor event while offering much needed shade. The Pinnacle tents are available in 6 sizes ranging from 3x3m up to a huge 10x10m. The frame is made from sturdy Aluminium with roofs made from 100% PVC fabric. Each tent can be upgraded with a range of accessories designed to improve the style and functionality of the tent. Upgrades include walls and windows walls for the square based and glass walls and doors, PVC window walls, and solid flooring systems for the hexagonal based range.

The 3x3m Pinnacle Range is perfect for a professional level commercial purpose. Covering 9 square metres, these structures offer a tall pagoda style roof in heavy duty 100% PVC. The Pinnacle Range is upgradable to include cassette style flooring, glass walls and a variety of other elegant trimmings.

Size: 3m x 3m
From $2,495 NZD

Frame Specifications
Eave Height: 2.5m
Ridge Height: 4.3m
Eave Connection: Hot-dip galvanized steel insert
Framework Material: Hard pressed extruded aluminum
6061/T6 (13HW)
Cover Material: PVC 750-900g/m2

Roof Fabrics
PVC 750-900 GSM

Printing
Full Roof Digital Printing available

Download PDF
Setup Instructions
Engineer Certification
Specification Sheet

The 4x4m Pinnacle Range is ideal for events that require an extra level of sophistication. Covering 16 square metres, these structures offer a tall pagoda style roof in heavy duty 100% PVC. The Pinnacle Range is upgradable to include cassette style flooring, glass walls and a variety of other elegant trimmings.

Size: 4m x 4m
From $2,795 NZD

Frame Specifications
Eave: Height 2.5m
Ridge: Height 4.8m
Clearance: 2m
Eave Connection: Hot-dip galvanized steel insert
Framework Material: Hard pressed extruded aluminium
6061/T6 (13HW)
Cover Material: PVC 750-900g/m2

Roof Fabrics
PVC 750-900g/m2

Printing
Full Roof Digital Printing available

Download PDF
Setup Instructions
Engineer Certification
Specification Sheet

The 5x5m Pinnacle Range is a clear span premium quality event tent. Covering 25 square metres, these structures boast a tall pagoda style roof in heavy duty 100% PVC. The Pinnacle Range is upgradable to include cassette style flooring, glass walls and a variety of other elegant trimmings.

Size: 5m x 5m
From $3,095 NZD

Frame Specifications
Eave: Height 2.5m
Ridge: Height 5.2m
Clearance: 2m
Eave Connection: Hot-dip galvanized steel insert
Framework Material: Hard pressed extruded aluminium
6061/T6 (13HW)
Cover Material: PVC 750-900g/m2

Roof Fabrics
PVC 750-900g/m2

Printing
Full Roof Digital Printing available

Download PDF
Setup Instructions
Engineer Certification
Specification Sheet

The 6x6m Pinnacle Range is a superior clear span event tent covering a huge 36 square metres. These structures boast a tall pagoda style roof in heavy duty 100% PVC. The Pinnacle Range is upgradable to include cassette style flooring, glass walls and a variety of other elegant trimmings.

Size: 6m x 6m
From $4,095 NZD

Frame Specifications
Eave: Height 2.5m
Ridge: Height 5.8m
Clearance: 2m
Eave Connection: Hot-dip galvanized steel insert
Framework Material: Hard pressed extruded aluminium
6061/T6 (13HW)
Cover Material: PVC 750-900g/m2

Roof Fabrics
PVC 750-900g/m2

Printing
Full Roof Digital Printing available

Download PDF
Setup Instructions
Engineer Certification
Specification Sheet

The 8x8m Pinnacle Range is a premium grade commercial event tent covering a massive 64 square metres. These structures boast a tall pagoda style roof in heavy duty 100% PVC. The Pinnacle Range is upgradable to include cassette style flooring, glass walls and a variety of other elegant trimmings.

Size: 8m x 8m
From $11,495 NZD

Frame Specifications
Eave: Height 2.6m
Ridge: Height 5.4m
Clearance: 2m
Eave Connection: Hot-dip galvanized steel insert
Framework Material: Hard pressed extruded aluminium
6061/T6 (13HW)
Cover Material: PVC 750-900g/m2

Roof Fabrics
PVC 750-900g/m2

Printing
Full Roof Digital Printing available

Download PDF
Setup Instructions
Engineer Certification
Specification Sheet

The 10x10m Pinnacle Range is the biggest square premium commercial event in our pinnacle range. This tent covers a massive 100 square metres without the need for any support within the perimeter of the structure. These structures boast a tall pagoda style roof in heavy duty 100% PVC. The Pinnacle Range is upgradable to include cassette style flooring, glass walls and a variety of other elegant trimmings.

Size: 10m x 10m
From $11,895 NZD

Frame Specifications
Eave: Height 2.6m
Ridge: Height 6.4m
Clearance: 2m
Eave Connection: Hot-dip galvanized steel insert
Framework Material: Hard pressed extruded aluminium
6061/T6 (13HW)
Cover Material: PVC 750-900g/m2

Roof Fabrics
PVC 750-900g/m2

Printing
Full Roof Digital Printing available

Download PDF
Setup Instructions
Engineer Certification
Specification Sheet
